CD10/Fe/N tweeter compression driver

CD10/Fe/N tweeter compression driver

Brief description: 70 W / > 1,2 kHz, 8 Ω, 109 dB with TD 164, 700 – 19 000 Hz, rec. cross. freq. > 1 200 Hz, voice coil 44,4 mm, polymer Pm4 dome, 1″

Suitable for: power tweeter section, for order 3pcs above, discount 20%

Cat. nr.: 02 281
80,37 € with VAT
in stock

 pc
Help needed? Services for free Recommend product
Catalogue page Detail datasheet Speaker box projects Next technical informations

Description

  • zatížitelnost 70 / >1200 Hz
  • impedance 8 Ω
  • Re 4,3 Ω
  • citlivost 109 s TD 164 dB/1W,1m
  • frekvenční rozsah 700 – 19 000 Hz
  • doporučená dělící frekvence > 1 200 Hz
  • Ø cívky 44,4 mm
  • materiál membrány polymer Pm4
  • materiál magnetu Ferit
  • rozměr A (vnější Ø) 100 mm
  • rozměr B (rozteč otvorů pro šroubky) 49,4 mm
  • rozměr C (vyústění) 1"
  • rozměr D (vnější hloubka) 62 mm
